One、 Feature
◆ 64-segment curve programming
◆ Automatic / manual bumpless switching
◆ Concise programming, can jump, loop
◆ RS485 communication, analog transmission function
Two、Technical parameters
1. Working power: AC / DC85 ～ 260V (other power can be customized)
2. Input signal: T, R, J, WRe3-25, B, S, K, E
Pt100, Cu50, 0 ～ 375Ω, 0 ～ 75mV
0 ～ 30mV, 0 ～ 5V, 1 ～ 5V, 0 ～ 10V, 0 ～ 10mA
0 ～ 20mA, 4 ～ 20mA
3. Accuracy: 0.2% FS ± 1 word
4. Sampling rate: 5 times / second
5. Feed output: DC24V / 25mA
6. Transmission output: 4 ～ 20mA, 0 ～ 20mA
7. Transmission load capacity: not less than 500Ω
8. Communication output: RS485 (MODBUS_RTU protocol)
9. SSR level: DC12V / 25mA
10. Operating environment: 0 ～ 50 ℃; ≤ 85% RH
